TCL TAC-24CHSD/XA73I

0 Review(s)

High Wall Inverter 24000BTU

Type: High Wall
Cooling Capacity: 24000 Btu
Energy Class Cooling: Α++
Energy Class Heating: A+++
Ionic Function: No

Sale Price: €689.00 €995.00

Accompanying services you might be interested in

Installation Air Conditioner

€130.00

At a Glance

24000

BTU/h

A++

Energy Class (Cooling)

A+++

Energy Class (Heating)

R32

Refrigerant

9-16 m²

Application Area

6.1

SEER

Turbo Cooling & Heating

Fast cooling brings coils down to 18°C within 30 seconds, while fast heating brings coils up to 40°C within 60 seconds. The inverter compressor runs at high frequency to deliver maximum capacity right when it's needed most.

TCL TAC-24CHSD/XA73I Turbo Cooling and Heating

Low Noise

A dedicated Silent mode drops the unit to its lowest noise output, for quieter operation when it matters.

4-Step Auto Clean

From frosting and defrosting to drying and sterilising, Auto Clean uses the air's natural water molecules to sweep away dust, dirt, and other impurities automatically at the touch of a button.

Extreme Cooling

The air-cooled E-Box keeps cooling running continuously even at 60°C ambient, with 100% cooling capacity maintained at up to 50°C ambient.

AI Inverter

Smart Inverter can save up to 60% on energy use, reaching the set temperature more quickly and holding it stable within ±1°C.

I FEEL

A sensor built into the remote, which typically stays close to you, closes the gap between the set temperature and how the room actually feels — so comfort is based on where you are, not just where the unit is.

Specifications

Tap a section to expand or collapse.

Basic Information

Brand

TCL

Model

TAC-24CHSD/XA73I

Type

High Wall Split (Inverter)

Cooling Capacity

24000 BTU/h

Cooling Energy Class

A++

Heating Energy Class

A+++

General

Rated Cooling Capacity [VERIFY — figure as listed does not match the 24000 BTU/h rating stated elsewhere on this page; confirm with TCL before publishing]

2600 W (940–3300 W)

Rated Heating Capacity

2610 W (940–3360 W)

Design Load in Cooling (Pdesignc)

2600 W

Seasonal Efficiency (SEER)

6.1 W/W

Energy Class in Cooling

A++

Cooling Efficiency (EER)

3.15 W/W

Heating Efficiency (COP)

3.4 W/W

Design Load in Heating (Pdesignh)

2600 W

Seasonal Efficiency (SCOP)

4.0 W/W

Heating Energy Class

A+

Rated Heating Capacity (-10°C)

1900 W

Spare Heating Capacity (-10°C)

700 W

Annual Energy Consumption (Cooling)

149 kWh

Annual Energy Consumption (Heating)

910 kWh

Application Area

9–16 m²

Electricity Supply

220–240V ~ / 50Hz / Single-phase

Power Supply Connection Location

Outdoor Unit

Voltage Range

165–265 V

Expansion Valve

Thermostatic

Settable Temperature Range

16–31°C

Performance

Working Current – Cooling

4.0 A (1.2–8.0 A)

Working Current – Heating

3.8 A (1.2–9.0 A)

Power Consumption – Cooling

825 W (240–1380 W)

Power Consumption – Heating

767 W (240–1552 W)

Dehumidification Capacity

1.0 L/h

Sound Levels

Indoor Unit Sound Power (Turbo/H/M/L/Silent)

50 / 47 / 43 / 35 / 32 dB(A)

Outdoor Unit Sound Power Level

60 dB(A)

Indoor Unit Sound Pressure (Turbo/H/M/L/Silent)

40 / 37 / 33 / 25 / 22 dB(A)

Outdoor Unit Sound Pressure Level

50 dB(A)

Air Flow & Fan

Indoor Unit Air Flow (Cooling / Heating)

420 / 420 m³/h

Indoor Unit Fan Type

Cross Flow

Indoor Fan Speed – Cooling (Turbo/H/M/L/Silent)

1400 / 1300 / 1100 / 1000 / 900 rpm

Indoor Fan Speed – Heating (Turbo/H/M/L/Silent)

1400 / 1300 / 1100 / 1000 / 900 rpm

Indoor Fan Speed – Dehumidification

1000 rpm

Outdoor Unit Fan Type

Axial Fan

Outdoor Unit Air Flow

1700 m³/h

Outdoor Fan Speed (Cooling / Heating)

930 / 930 / 830 / 730 / 630 rpm

Refrigerant

Type / Amount / GWP / CO2 Equivalent

R32 / 0.45 kg / 675 / 0.304 ton

Dimensions and Weight

Indoor Unit Dimensions (W x H x D)

698 x 255 x 190 mm

Indoor Unit Net Weight

6.5 kg

Indoor Unit Packaging Dimensions

764 x 325 x 257 mm

Indoor Unit Gross Weight

8.5 kg

Outdoor Unit Dimensions (W x H x D)

712 x 459 x 276 mm

Outdoor Unit Net Weight

22 kg

Outdoor Unit Packaging Dimensions

765 x 481 x 310 mm

Outdoor Unit Gross Weight

25 kg

Installation

Interconnection Cable

4 x 0.75 mm²

Power Supply Cable

3 x 1.5 mm²

Copper Pipe – Liquid Side

1/4"

Copper Pipe – Gas Side

3/8"

Max Copper Pipe Length

25 m

Max Level Difference (Indoor–Outdoor)

10 m

Operating Conditions

Indoor Temperature Range (Cooling / Heating)

17–32°C / 0–30°C

Outdoor Temperature Range (Cooling / Heating)

-15–53°C / -20–30°C

Specs may vary by region. Always verify with official manufacturer documentation.
