TCL TAC-18CHSD/XA73I

0 Review(s)

High Wall Inverter 18000BTU

Type High Wall
Cooling Capacity (Btu/ hr) 18000 Btu
Energy Class Cooling Α++
Energy Class Heating A+++
Ionic Function No

Sale Price: €599.00 €745.00

Accompanying services you might be interested in

Installation A/C 18000 - 24000 BTU

€130.00

5 fan speeds

The device is equipped with 5 internal unit fan speeds: turbo, high, medium, low and silent.

Filter cleaning alarm

It reminds you when the filter needs to be cleaned, with a notification appearing on your device's display or in the TCL HOME app.

Anti Cold

This function prevents cold air from blowing into the room when the heating mode is turned on. The indoor unit fan starts working at the lowest speed and its speed gradually increases as the indoor unit heat exchanger temperature increases.

Mute mode

Thanks to the unique internal construction, the sounds generated by the device are kept to a minimum.

Extended Specifications

Power

Cooling (min - rated - max) kW: 1.25 - 5.10 - 5.91
Heating (min. - rated - max.) kW: 1.25 - 5.10 - 6.07

Efficiency

SEER/SCOP (In/In): 6.1 / 4.0
Energy efficiency class | cooling / heating: A++ / A+
Electricity consumption | cooling / heating (kWh/a): 293 / 1330
Moisture removal (l/h): 1.5
Indoor unit air flow | cooling / heating m 3 /h: 800 / 800
Outdoor unit air flow m 3 /h: 2600
Indoor unit sound pressure (turbo / H / M / L / mute) dB(A): 43 / 41 / 38 / 35 / 27
Sound pressure of outdoor unit dB(A): 55
Indoor unit sound power (turbo / H / M / L / mute) dB(A): 53 / 50 / 47 / 43 / 36
Sound power of the outdoor unit dB(A): 65
Indoor unit operating temperature range | cooling / heating °C: from 17 to 32 / from 0 to 30
Outdoor unit operating temperature range | cooling / heating °C: -15 to 53 / -20 to 30
Indoor unit temperature setting range °C: from 16 to 31

Electrical data

Power Source (V / Hz / P): 220-240 / 50 / 1
Operating current (min - nom - max) | cooling (AND): 1.7 - 8.1 - 12.0
Operating current (min. - nom. - max.) | heating (AND): 1.7 - 7.0 - 13.0
Power consumption (min - nom - max) | cooling (kW): 0.33 - 1.58 - 2.34
Power consumption (min. - nom. - max.) | heating (kW): 0.34 - 1.37 - 2.52

Dimensions

Net dimensions of indoor unit (W x H x D) mm: 910×294×206
Net dimensions of outdoor unit (W x H x D) mm: 853×602×349
Gross dimensions of indoor unit (W x H x D) mm: 979×372×277
Gross dimensions of outdoor unit (W x H x D) mm: 890×628×385
Net weight of indoor unit kg: 10.0
Net weight of outdoor unit kg: 35.0
Gross weight of indoor unit kg: 13.0
Gross weight of outdoor unit kg: 38.0
